Defender 25 Motor

The new Defender 25 Motor designed for ultralight build, that micro drone change FPV in nowadays. Sub 250grams Defender 25 builds like these just got much nicer since we got the newest generation whoop style all in one (AIO) with iflight new Defender 25 frame you can build the ultralight micro drone.

Model: Defender 25 Motor

KV: 4150kV

Weight(included wire): 8g±0.5g

Dimension: φ17.7*12.5mm

Interphase Resistance:  188mΩ

Input Volts: 4S

Peak Current: 12.03A

Max Watt: 200.8W

Mounting Holes: 3 x 9*9 φ2mm (3 mounting holes)

Rotor Specifications: Segmented bell

Shaft Diameter: 1.5mm

Shaft Protruding Length: 1.8mm±0.2mm

Lead: 60mm/26AWG

Magnet: N52H Curved

Configuration: 9N12P

Bearing Type: NMB

Bearing Specification: φ5*φ2*2.5

Winding: Single Strand copper winding

1 x Defender 25 1404 Motor

4 x M2x5 mounting screws

2 x M2x7 mounting screws
