Description
This is a new generation F411 AIO designed for Defender 25. A future proof all-in-one FC to step up the game. Lightweight, minimum size, minimum work. Solder your motor wires on and let's go!
Compability
This AIO is made for Defender 25 Analog only.
FC Specifications
MCU: STM32F411
Gyro: ICM42688
Connector: Micro
Blackbox: 8MB
INA pad: n uart2
Barometer: Yes
Weight: 7.5g±0.1g
Mounting pattern: 25.5*25.5mm/φ3mm
Dimensions: 30.5*30.5mm
FC Firmware: IFLIGHT_F411_PRO (BF4.4.2)
ESC Specifications
Output current: 20A, peak value 25A (10 seconds)
Current sensor: yes
Telemetry: no
ESC Firmware: Bluejay Q-H-50 (8bit ESC)
Input voltage: 2-4S
Packing List
1 x Defender 25 BLITZ F411 Analog AIO
4 x M2 silicon grommets
Note
iFlight product is for fun purposes only and does not support autonomous flight.
:
Were can I find the Firmware for this FC? The Target IFLIGHT_BORG_H7 is not listet in the Betaflight 2026.6.2 Webapp
2026-11-12 03:13:49
Answer:
Due to policy restrictions, we have updated the firmware on Google Drive. Please find the attached firmware:
https://drive.google.com/file/d/1m3KuTu_r3GMaa04d1fYL6zsRfSYDYWbR/view?usp=drive_link
-------iFlight Support Team
:
Does each motor channel have independent current sensing and configurable current protection in BLHeli_32? Also, does it support Bidirectional Dshot?
2026-11-11 19:29:24
Answer:
Regarding current sensing, this 4-in-1 ESC typically monitors the total current via a single sensor for protection, rather than providing independent, configurable per-channel monitoring.
Yes, this ESC natively supports Bidirectional DShot.
-------iFlight Support Team
