BLITZ Whoop AIO F411

BLITZ Whoop AIO F411

Availability: In Stock
$62.99 $64.99 SAVE $1
Tags:
Specifications

Size: 30.5*30.5mm

Mounting pattern: 25.5*25.5mm/φ3mm

Weight: 7.5g

MCU: STM32F411

Gyro: BMI270

Blackbox: 8MB

BEC  output: 5V 2A

Config：IFLIGHT_F411_PRO.config

INA pad: nR2

Barometer: No

Constant current: 20A，25A（Burst）

Input: 2-4S

Current sensor: yes

BLHeli: BLHeli-S

ESC Telemetry: no

Firmware Target: IFLIGHT_F411_PRO

ESC Firmware: Bluejay Q-H-50

Packing List

1 x BLITZ Whoop AIO F411

yoki 21/07/2021
good AIO FC, very small and compact, I'm new in FPV, I didn't take care long flight time will cause overheating issue, I burned out first one, bought this one to replace old one
filip 24/06/2021
Tried this I-flight whoop flight controller and best whoop board for a built in DJI Air connector . Well packaged and received in great time!
quain 23/06/2021
Very good F4 toothpick FC with 20A ESC's and with a blackbox !
Cook 17/06/2021
Bien emballée. Avec tout le nécessaire de montage. Et une connectique XT30 avec condensateur.
Aaron 26/05/2021
perfect for my new 2.5 inch build super cheap

Write a review

Please login or register to review
  • Whoop AIO F411 V1.1 Wiring Diagram V2.0 18/03/2025 14.05MB
  • Whoop AIO F411 V1.1 Wiring Diagram V1.0 05/07/2023 1.66MB
