XING 1504 FPV Motor - Black
$16.99
Price drop reminder
In Stock
If the price of the product is reduced within 30 days, we will notify you via email, SMS and mobile client~
If the goods arrive within 30 days, we will notify you via email, SMS and mobile client~
$16.99
Related Products
Specifications
Model: XING 1504 Black Motor
KV: 3100KV
Weight(included wire): 12.3g
Dimension: φ21.6*18.5mm
Interphase Resistance: 247mΩ
Input Volts: 16.8V
Peak Current: 12.44A
Max Watt: 207W
Mounting Holes: 9*9 φ2mm
Rotor Specifications: Unibell
Shaft Diameter: 1.5mm
Shaft Protruding Length: 4.0mm
Configuration: 12N14P
Bearing Type: NSK
Bearing Specification: φ5*φ2*2.5
Winding: Single Strand copper winding
Packing List
1 x XING 1504 3100KV Motor
4 x M2*5 screws
2 x M2*7 screws
Vadym:
On IFlight Europe shop this motor is 6s. Is that true? Do you have test report for 6s? Thank you.
2026-03-30 21:03:49
Answer:
The input voltage of this motor is 16.8V, not 6S. There may be an error in the information on the European website, and we will further verify it. Therefore, we are unable to provide the corresponding 6S test report. The corresponding datasheet has been uploaded in the link, please check it: https://shop.iflight.com/XING-1504-FPV-Motor-Black-Pro1969
2026-04-01 14:17:21
