XING-E 3314 Cinelifter Motor
$41.99
Price drop reminder
- Availability: In Stock
Optional
If the price of the product is reduced within 30 days, we will notify you via email, SMS and mobile client~
If the goods arrive within 30 days, we will notify you via email, SMS and mobile client~
Changelog
March 11, 2024: The motor's Shaft Protruding Length is available in 15mm and 17mm specifications and will be sent out randomly.
Specifications
Model: XING-E 3314 Motor
KV: 900KV
Weight(included wire): 120g
Dimension: φ38.6*46.8mm
Interphase Resistance: 48.1mΩ
Input Volts: 24V
Peak Current: 58.48A
Max Watt: 1366.1W
Mounting Holes: 19*19 φ3mm
Shaft Diameter: 5mm
Rotor Specifications: Segmented bell
Shaft Protruding Length: 15mm / 17mm
Lead: 400mm/16AWG
Magnet: N52H Curved
Configuration: 12N14P
Bearing Specification: φ11*φ5*5
Winding: Single Strand copper winding
Packing List
1 x XING-E 3314 900KV Brushless Motor
4 x M3*10 screws
1 x M5 Flange Nut
